MS-9642 Mainboard
1-2
Mainboard Specifications
Processor
- Intel
®
Core 2 Duo/Core Duo/Core Solo/Celeron M/Celeron LV
423 BGA (with BGA Passive Cooler) CPU in Socket M
- Supports 3 pin CPU Fan Pin-Header with Fan Speed Control
- Supports Intel Dual Core Technology to 533/667MHz and up
Chipset
- North Bridge: Intel
®
945GM/ 945GME chipset
- South Bridge: Intel
®
ICH7M chipset
Memory
- DDR2 533/667 SDRAM (2GB Max)
- 1 DDR2 DIMM slot (240pin / 1.8V)
LAN
- Supports 3 PCI Express Gb Ethernet by Intel
®
82573L or one
Intel
®
82562GZ 10/100 LAN (optional)
Audio
- HDA Codec by Realtek
®
ALC888 7.1 channel
- Compliant with Azalia 1.0 Spec.
- 6 watt amplifier (optional)
IDE
- 1 IDE port by ICH7M
- Supports Ultra DMA 66/100 mode
- Supports PIO, Bus Master operation mode
SATA
- SATA ports by ICH7M
- Supports two SATA devices
- Supports storage and data transfers at up to 150MB/s
