MSI H81M-P33 Series User Guide

English
12
Motherboard Speci󰘰cations
CPU
Support
4th Generation Intel
®
Core™ i7 / Core™ i5 / Core™ i3 /
Pentium
®
/ Celeron
®
processors for LGA 1150 socket
■
Chipset Intel
®
H81/ H87/ B85 Express Chipset■
Memory
Support
2x DDR3 memory slots supporting up to 16GB
Supports DDR3 1600/ 1333/ 1066 MHz
Dual channel memory architecture
Supports non-ECC, un-bu󰘯ered memory
■
■
■
■
Expansion
Slots
1x PCIe x16 slot (optional)
1x PCIe 2.0 x1 slot
■
■
Onboard
Graphics
1x HDMI port (optional), supporting a maximum resolution of
2560x1600@60Hz, 24bpp/ 1920x1080@60Hz, 36bpp
1x DVI-D port (optional), supporting a maximum resolution of
1920x1200 @ 60Hz, 24bpp
1x VGA port, supporting a maximum resolution of 1920x1200
@ 60Hz, 24bpp
■
■
■
Storage Intel H81/ H87/ B85 Express Chipset
4x SATA ports (optional)
Supports RAID 0, RAID1, RAID 5 and RAID 10 (optional)
Supports Intel Smart Response Technology (optional)*
Supports Intel Rapid Start Technology (optional)*
Supports Intel Smart Connect Technology (optional)*
* Supports Intel Core processors on Windows 7 and Windows 8
■
-
-
-
-
-
USB Intel H81/ H87/ B85 Express Chipset
2x USB 3.0 ports on the back panel
8x USB 2.0 ports (4 ports on the back panel, 4 ports avail-
able through the internal USB connectors*)
■
-
-
Audio Realtek
®
ALC887 Codec■
LAN Realtek
®
RTL8111G Gigabit LAN controller■
Back Panel
Connectors
1x PS/2 keyboard port
1x PS/2 mouse port
4x USB 2.0 ports
2x USB 3.0 ports
1x HDMI port (optional)
1x DVI-D port (optional)
1x VGA port
1x LAN (RJ45) port
3x audio jacks
■
■
■
■
■
■
■
■
■

MSI H81M-P33 Series Specifications

General

Form Factor	Micro ATX
Chipset	Intel H81
Socket	LGA 1150
Memory Slots	2 x DIMM
Maximum Memory	16 GB
Memory Standard	DDR3 1600/ 1333 MHz
PCIe Slots	2 x PCIe 2.0 x1
SATA Ports	2 x SATA 6Gb/s, 2 x SATA 3Gb/s
USB 3.0 Ports	2
USB 2.0 Ports	6
Audio	Realtek ALC887
LAN	Realtek RTL8111G Gigabit LAN
Video Outputs	1 x DVI-D, 1 x VGA
