E-1-5
Getting Started
USB Interface
h 10 USB ports
- Controlled by nForce4 Ultra chipset
- 4 ports in the rear I/O, 6 ports via the external bracket
NV RAID (Software)
h Supports up to 4 SATA and 4 ATA133 Hard drives
- RAID 0 or 1, 0+1, JBOD is supported
- RAID function available for PATA+SATA H/D drives
Silicon Image’s SATARAID5
TM
(Software) (Optional)
h RAID 0 or 1, RAID5, RAID10, and JBOD groups are supported
h Support up to 4 SATA devices connected to a single controller
Dual LAN (Optional)
h Supports dual LAN jacks
- 1st LAN supports 10/100/1000 Fast Ethernet by Marvell 88E1111
- 2nd LAN supports 10/100/1000 Fast Ethernet by Marvell 88E8053
IEEE 1394 (Optional)
h Supports up to two 1394 ports (rear panel x 1, pinheader x 1). Transfer rate is
up to 400Mbps
Audio
h Chip integrated by Realtek ALC850
- Direct Sound AC97 audio
- 7.1 Channel output
On-Board Peripherals
h On-Board Peripherals include:
- 1 floppy port supports 1 FDD with 360K, 720K, 1.2M, 1.44M and 2.88Mbytes
- 1 serial port
- 1 parallel port supporting SPP/EPP/ECP mode
- 1 Audio jack(5-in-1), coaxial/fiber SPDIF out
- 1 IrDA pinheader
- 1 CD-In pinheader
- 1 D-Bracket2 pinheader
- 2 IEEE1394 ports (Rear * 1 / Front * 1)(Optional)
- 10 USB1.1/2.0 ports (Rear * 4 / Front * 6)
To Next Page
