1-5
Getting Started
MSI Special Features
Color Management
MSI has a unified color management rule for some connectors on the
mainboards, which helps you to install the memory modules, expansion cards
and other peripherals devices more easily and conveniently.
† Intel spec IDE ATA133 connector: yellow
† Serial ATA150 connector: orange
† AGP 8X slot: red
† USB 2.0 connector: yellow
† Front panel connector JFP1: HDD LED in red, Reset Switch in blue,
Power Switch in black, Power LED in light green.
† Front panel connector JFP2: Power LED in light green.
Front Panel Connector JFP2
USB 2.0 Connectors
AGP Slot
Intel Spec IDE ATA133 Connectors
Front Panel Connector JFP1
Serial ATA Connectors
To Next Page
