1-3
Getting Started
- 1 serial port
- 1 parallel port supports SPP/EPP/ECP mode
- 3 audio ports in vertical
- 1 RCA SPDIF-Out
- 1 D-Bracket 2 pinheader
- 1 RJ-45 LAN Jack
Audio
† AC’97 link controller integrated in VIA 8237
† 5.1 Channel audio supported by Realtek ALC655 codec
- Compliance with AC’97 v2.2 spec.
- Meet PC2001 audio performance requirement
BIOS
† The mainboard BIOS provides “Plug & Play” BIOS which detects the pe-
ripheral devices and expansion cards of the board automatically.
† The mainboard provides a Desktop Management Interface (DMI) function
which records your mainboard specifications.
Dimension
† ATX Form Factor: 29.5 cm (L) x 20.5 cm (W)
Mounting
† 6 mounting holes
Others
† Suspend to RAM/Disk (S3/S4)
† PC2001 compliant
