MSI MAG B560M MORTAR WIFI - Jdash1: 튜닝 컨트롤러 커넥터; Jfp1, Jfp2: 전면 패널 커넥터

23
󺭞󻼣󽉺󺨎󼒆
󼗶󻡦󽄚󺼂󼳖󺼗󼼢
󼕦󼳖󺼗󼼢󻝮󻺞󼒛󽍊󼏞󼗶󻡦󽄚󺼂󼏂󼕺󻂆󼂖󼓶󼱊󻨁 󻝮󼏢󺪢󽍒󼀊󼕺󼂧󻂺󻃖 
1
2 10
9
+
+
+  
+
󼗶󼓂
HDD LED 󻞞󻼽󼂖󼓶󼱊
Reserved
󼗶󼓂󼂖󼓶󼱊
JFP1
1 HDD LED + 2 Power LED +
3  4 
5 Reset Switch 6 Power Switch
7 Reset Switch 8 Power Switch
9 Reserved 10 No Pin
1
JFP2
+
+


Speaker
Buzzer
1  2 Buzzer +
3  4 Speaker +
󽂎󻃏󼳚󽂪󻙖󻗞󼳖󺼗󼼢
󼕦󼳖󺼗󼼢󻝮󻺞󼒛󽍊󼏞󼐧󻽊󼕪󽂎󻃏󼳚󽂪󻙖󻗞󻢚󻊺󼔶󼏢󺪢󽍒󼀊󼕺󼂧󻂺󻃖 
1
2 6
5
1 No Pin 2 NC
3 MCU_SMB_SCL_M 4 MCU_SMB_SDA_M
5 VCC5 6 Ground
