MSI MAG B560M MORTAR WIFI - Rear I;O Panel; LAN Port LED Status Table; Audio Ports Configuration

12
Package contents

Audio Ports

2 4 6 8
  
Rear Speaker Out   
 
    
Mic In
Blank: empty)
LAN Port LED Status Table
Link/ Activity LED
Status Description
Off No link
Yellow Linked
Blinking Data activity
Speed LED
Status Description
Off 10 Mbps connection
Green 100/1000 Mbps connection
Orange 2.5 Gbps connection
Rear I/O Panel
2.5 Gbps LAN
Audio Jacks

connectors
DisplayPort

USB 3.2 Gen 1

For MAG B560M
MORTAR WIFI only
USB 3.2 Gen 2x2


