MSI MAG B660 TOMAHAWK WIFI DDR4

24
󺭞󻼣󽉺󺨎󼒆
24
131
12
ATX_PWR1
1 +3.3V 13 +3.3V
2 +3.3V 14 
3 Ground 15 Ground
4 +5V 16 
5 Ground 17 Ground
6 +5V 18 Ground
7 Ground 19 Ground
8 PWR OK 20 Res
9 5VSB 21 +5V
10 +12V 22 +5V
11 +12V 23 +5V
12 +3.3V 24 Ground
5
4 1
8
CPU_PWR1~2
1 Ground 5 +12V
2 Ground 6 +12V
3 Ground 7 +12V
4 Ground 8 +12V

󼜃󼒆󻺞󽍟
󻢚󻋒󼗶󼓂󼳲󼕦󻰆󼕦󼗶󼓂󺫧󺯻󼖗󼱊󼏂󼐞󻨆󻝦󺩾󼏢󺪢󻈊󼎦󻡆󼕪󻫦󻋎󺧲󼌺󼘇󼗳󼔮󻙎
󼖃󻇋󽍊󻂆󼞲󽑇󼕪󽍊󼃟󼃎󼐖 
󼗶󼓂󼳖󺼗󼼢
󼕦󼳖󺼗󼼢󻝮󻺞󼒛󽍊󼏞󼗶󼓂󺫧󺯻󼖗󼱊󻝮󼏢󺪢󽍒󼀊󼕺󼂧󻂺󻃖 
