Specifications
Continued from previous page
Internal Connectors
y 1x 24-pin ATX main power connector
y 2x 8-pin ATX 12V power connector
y 1x flat 4-pin ATX 12V power connector*
y 8x SATA 6Gb/s connectors
y 2x USB 2.0 connectors (supports additional 4 USB 2.0
ports)
y 2x USB 3.1 Gen1 connectors (supports additional 4 USB 3.1
Gen1 ports)
y 1x USB 3.1 Gen2 Type-C port
y 1x 4-pin CPU fan connector
y 1x 4-pin Water Pump connector
y 5x 4-pin system fan connectors
y 3x 4-pin extend fan connectors
y 2x Front panel connectors
y 1x Front panel audio connector
y 2x 5050 RGB LED strip 12V connector (JRGB1~2)
y 1x WS2812B Individually Addressable RGB LED strip 5V
connector (JRAINBOW1)
y 1x CORSAIR connector (JCORSAIR1)
y 1x TPM module connector
y 3x 2-pin Thermal Sensors connectors
* Provides additional power to PCIe x16 slots
Internal Buttons
y 1x GAME BOOST knob
y 1x Power button
y 1x Reset button
Jumper
y 1x Clear CMOS jumper
y 1x OC retry connector
y 1x OC force enter BIOS connector
y 1x Chassis Intrusion connector
y 1x Slow mode connector
y 1x JBLK_U1 connector
y 1x JBLK_D1 connector
Debug LED y 1x 2-Digit Debug Code LED
