MSI MEG X570 ACE User Manual

5
Specifications
Continued from previous page
LAN
1x Intel
®
WGI211AT Gigabit LAN controller
1x Realtek
®
RTL8125 2.5 Gbps LAN controller
Wireless LAN &
Bluetooth
®
Intel
®
Wi-Fi 6 AX200
 Supports 802.11 a/b/g/n/ac/ax, MU-MINO Rx, 2.4GHz-
5GHz (160MHz) up to 2.4Gbps
 Supports Bluetooth
®
5
 The Wireless module is pre-install in the M2_4 (Key-E)
slot
Audio
Realtek
®
ALC1220 Codec
y 7.1-Channel High Definition Audio
y Supports Optical S/PDIF output
Storage
AMD
®
X570 Chipset
y 4x SATA 6Gb/s ports
y 2x M.2 slots (M2_2/ M2_3, Key M)*
 Support PCIe 4.0/ 3.0 x4 and SATA 6Gb/s
 Support 2242/ 2260 /2280 storage devices
AMD
®
Processor
y 1x M.2 slot (M2_1, Key M)*
 Supports PCIe 4.0 x4 (3rd Gen AMD Ryzen™)
 Supports PCIe 3.0 x4 (2nd Gen AMD Ryzen™/ Ryzen™
with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™
with Radeon™ Graphics)
 Supports 2242/ 2260 /2280/ 22110 storage devices
*The speeds may vary for different devices
RAID
AMD
®
X570 Chipset
y Supports RAID 0, RAID 1 and RAID 10
Continued on next page

MSI MEG X570 ACE Specifications

General

Processor socket	Socket AM4
Processor manufacturer	AMD
Compatible processor series	AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Maximum number of SMP processors	1
Audio chip	Realtek ALC1220
Component for	PC
Motherboard chipset	AMD X570
Audio output channels	7.1 channels
Motherboard form factor	ATX
Number of mounting holes	9
Windows operating systems supported	Windows 10 Pro x64
ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	1866, 2133, 2400, 2667, 2800, 2933, 3000, 3066, 3466, 3733, 3866, 4000, 4133, 4400, 4600 MHz
RAID levels	0, 1, 10
Supported storage drive interfaces	SATA III
DirectX version	12.0
Parallel processing technology support	2-Way CrossFireX, 3-Way CrossFireX
USB 2.0 connectors	2
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
Number of M.2 (M) slots	3
BIOS type	UEFI AMI
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Intel WGI211AT, Realtek RTL8125
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.0
Ethernet interface type	2.5 Gigabit Ethernet, Gigabit Ethernet
Cables included	SATA
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	244 mm
Width	305 mm
