MSI MEG X670E GODLIKE

i
Block Diagram
MEG X670E GODLIKE
CHIPSET_B
PCIe 5.0x16 PCI_E1
PCIe 5.0x8 PCI_E2
PCIe 5.0x4 PCI_E3
USB3.2 Gen2x2 20Gbps
(Type-C)
ASM3241
DDR5
DIMM A1/A2
DIMM B1/B2
GEN5 x4 M.2_1
(PCIe Only)
GEN4 x4 M.2_2
(PCIe Only)
GEN4 x4 M.2_2 / M.2_3
(PCIe Only)
USB3.2 Gen2x2 20Gbps
(Type-A)
USB3.2 Gen2x2 20Gbps
(Type-C)
USB3.2 Gen2 10Gbps
(Type-A)
Aquantia AQC113
10Gbps LAN
SATA_P3 , P4
USB2.0
(Front Type-A)
SATA_A1_A2
ASM1061
SATA_B1_B2
ASM1064
SATA_B3_B4
Intel I225V
2.5Gbps LAN
WiFi 6E
USB3.2 Gen2x2 20Gbps
(Front Type-C)
CHIPSET_A
HD Audio
ALC4082
USB3.2 Gen2 5Gbps
(Front Type-A)
USB3.2 Gen2 5Gbps
(Front Type-A)
CPU
PCIE x4
PCIE x4
