Onboard LEDs

Hexadecimal Character Table

Hexadecimal 0 1 2 3 4 5 6 7 8 9 A B  D E F



LED display

0 1 2 3 4 5 6 7 8 9 A B C D E F

Boot Phases

Security (SEC)

Pre-EFI Initialization (PEI) – memory initialization

Driver Execution Environment (DXE) – main hardware initialization

Boot Device Selection (BDS)



Debug Code LED Table

SEC Progress Codes

01 

02 AP initialization before microcode loading

03 System Agent initialization before microcode loading

04 

06 Microcode loading

07 AP initialization after microcode loading

08 System Agent initialization after microcode loading

09 

0B 

SEC Error Codes

0C - 0D 

0E Microcode not found

0F Microcode not loaded

PEI Progress Codes

10 

11 

12 - 14 

15 

16 - 18 

19 

1A - 1C 

2B 

2C Memory initialization. Memory presence detection

2D Memory initialization. Programming memory timing information
