MSI MEG Z690 ACE - M2_2 & M2_3 slot Installation

39
Overview of Components
7. Put the M.2 SHIELD FROZR heatsink back in place and secure it.
M2_2 & M2_3 slot Installation
1. Loosen the screws of M.2 SHIELD FROZR heatsink.
2. Remove the M.2 SHIELD FROZR and remove the protective films from the thermal
pads.
1
1
2
M2_2 & M2_3
