Компоненты материнской платы

PCI_E1~5: Слоты расширения PCIe

⚠

Внимание!

∙



MSI Gaming Series Graphics Card Bolster



∙



PCI_E1.

∙









∙





Таблица комбинации для слотов M.2 и PCIe

Слот Комбинация

M2_1 (CPU) PCIe/SATA

M2_2 (PCH) PCIe x2 PCIe x4 X X

PCI_E1 (CPU)    

PCI_E2 (PCH)  X  X

PCI_E3 (PCH)  X PCIe x2 PCIe x4

PCI_E4 (PCH)    

PCI_E5 (PCH)    





BAT1

PCI_E1: PCIe 3.0/ 4.0 x16 (CPU)

PCI_E3: PCIe 3.0 x4 (PCH)

PCI_E2: PCIe 3.0 x1 (PCH)

PCI_E4: PCIe 3.0 x1 (PCH)

PCI_E5: PCIe 3.0 x1 (PCH)
