MSI MPG B760I EDGE WIFI DDR4

27
M2_1~2: M.2 Slots (Key M)
M2_1

Important
Intel® RST only supports PCIe M.2 SSD with UEFI ROM.
M2_2
Installing M.2 module into M2_1 slot
1. Loosen the screws of M.2 Shield Frozr heatsink.
2. Lift up the M.2 Shield Frozr heatsink and remove it.
11
11
22
3. Secure the supplied M.2 standoff.
33
