Specifications
CPU
Supports 13th and 12th Gen Intel® Core™ Processors,
Pentium® Gold and Celeron® Processors
Processor socket LGA1700
* Please go to www.msi.com to get the newest support status as new
processors are released.
Chipset Intel® B760 Chipset
Memory
2x DDR4 memory slots, supporting up to 64GB*
Supports 1R 2133/ 2666/ 3200 MHz (by JEDEC & POR)
Max. overclocking frequency:
1DPC 1R Max speed up to 5333+ MHz
1DPC 2R Max speed up to 4800+ MHz
Supports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supports Intel® Extreme Memory Profile (XMP)
* Please refer to www.msi.com for more information on compatible memory
Expansion Slot
1x PCIe x16 slot (From CPU)
• Supports up to PCIe 5.0 x16
Onboard Graphics
1x HDMI™ 2.1 port with HDR, supports a maximum
resolution of 4K 60Hz*/ **
1x DisplayPort 1.4 port with HBR3, supports a maximum
resolution of 8K 60Hz*/ **
*Available only on processors featuring integrated graphics.
** Graphics specifications may vary depending on the CPU installed.
SATA Ports
4x SATA 6Gb/s ports (From B760 chipset)
M.2 SSD Slots
2x M.2 slots (Key M)
• M2_1 slot (from CPU)
• Supports PCIe 4.0 x4
• Supports 2280 storage devices
• M2_2 slot (from B760 chipset)
• Support PCIe 4.0 x4
• Support SATA 6Gb/s*
• Support 2280 storage devices
* The SATA8 port will be unavailable when installing M.2 SATA SSD into M2_2.
Continued on next column
