15
Continued from previous column
RAID
Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA
storage devices
Audio
Realtek® ALC897 Codec
 7.1-Channel High Definition Audio
LAN
1x Realtek 8125B 2.5Gbps LAN controller
Wireless LAN &
Bluetooth®
Intel® Wi-Fi 6E
 The Wireless module is pre-installed in the M.2 (Key-E)
slot
 Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz*
(160MHz) up to 2.4Gbps
 Supports 802.11 a/ b/ g/ n/ ac/ ax
 Supports Bluetooth® 5.3**, FIPS, FISMA
* Wi-Fi 6E 6GHz may depend on every country’s regulations and will be ready in
Windows 10 build 21H1 and Windows 11.
** Bluetooth 5.3 will be ready in Windows 10 build 21H1 and Windows 11.
Power Connectors
 1x 24-pin ATX main power connector
 1x 8-pin 12V power connector
Internal USB
Connectors
Intel® B760 Chipset
 1x USB 3.2 Gen 2 10Gbps Type-C ports
 1x USB 3.2 Gen 1 5Gbps connectors
• Supports additional 2 USB 3.2 Gen 1 5Gbps ports
 1x USB 2.0 Type-A connectors
• Supports additional 2 USB 2.0 ports
Fan Connectors
 1x 4-pin CPU fan connector
 1x 4-pin water-pump fan connector
 1x 4-pin system fan connector
System Connectors
 1x Front panel audio connector
 2x System panel connectors
 1x Chassis Intrusion connector
 1x TPM module connector
Jumpers  1x Clear CMOS jumper
Continued on next column

MSI MPG B760I EDGE WIFI DDR4 Specifications

General

Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium Gold
Supported processor sockets	LGA 1700
Maximum number of SMP processors	1
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	5333, 5200, 5066, 5000, 4800, 4600, 4533, 4400, 4266, 4000, 3866, 3733, 3600, 3466, 3333, 3200, 3000, 2933, 2800, 2666, 2400, 2133 MHz
Supported memory clock speed (max)	5333 MHz
Wi-Fi standards	802.11a, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
Bluetooth version	5.3
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Ethernet interface type	2.5 Gigabit Ethernet
Number of SATA III connectors	4
DisplayPort version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	0
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	M.2, SATA III
BIOS type	UEFI AMI
BIOS memory size	256 Mbit
System Management BIOS (SMBIOS) version	3.5
Parallel processing technology support	-
Audio chip	Realtek ALC897
Component for	PC
Power source type	ATX
Motherboard chipset	Intel B760
Audio output channels	7.1 channels
Motherboard form factor	mini ATX
Windows operating systems supported	Windows 10, Windows 11

Weight and Dimensions

Width	170 mm
