MSI MPG B760I EDGE WIFI DDR4

16
Continued from previous column
LED Features
 1x 4-pin RGB LED connector
 1x 3-pin ARGB V2 LED connector
 4x EZ Debug LED
Back Panel
Connectors
 4x USB 3.2 Gen 1 5Gbps Type-A ports (From Hub GL3523)
 1x DisplayPort
 1x HDMI™ port
 1x USB 3.2 Gen 2 10Gbps Type-C port (From B760
chipset)
 1x USB 3.2 Gen 2 10Gbps Type-A port (From B760
chipset)
 2x USB 2.0 Type-A ports (From B760 chipset)
 1x 2.5G LAN (RJ45) port
 2x Wi-Fi Antenna connectors
 3x audio jacks
I/O Controller NUVOTON NCT6687D-M Controller Chip
Hardware Monitor
 CPU/ System/ Chipset temperature detection
 CPU/ System/ Pump fan speed detection
 CPU/ System/ Pump fan speed control
Form Factor
 Min-ITX Form Factor
 6.7 in. x 6.7 in. (17 cm x 17 cm)
BIOS Features
 1x 256 Mb flash
 UEFI AMI BIOS
 ACPI 6.4, SMBIOS 3.5
 Multi-language
Software
 Drivers
 MSI Center
 Intel XTU
 MSI APP Player (BlueStacks)
 CPU-Z MSI GAMING
 Norton 360 Deluxe
 AIDA64 Extreme - MSI Edition
