MSI MPG X570-A PRO User Manual

16
Specifications
Continued from previous page
Storage
y 6x SATA 6Gb/s ports
y 2x M.2 slots (Key M)*
 M2_1 slot (from AMD
®
Processor)
 Supports PCIe 4.0 x4 (3rd Gen AMD Ryzen™)
 Supports PCIe 3.0 x4 (2nd Gen AMD Ryzen™/ Ryzen™
with Radeon™ Vega Graphics and 2nd Gen AMD
Ryzen™ with Radeon™ Graphics)
 Supports 2242/ 2260/ 2280/ 22110 storage devices
 M2_2 slot (from AMD
®
X570 Chipset)
 Supports PCIe 3.0 x4 and SATA 6Gb/s
 Supports 2242/ 2260/ 2280 storage devices
RAID
AMD
®
X570 Chipset
y Supports RAID 0, RAID 1 and RAID 10
Audio
Realtek
®
ALC1220 Codec
y 7.1-Channel High Definition Audio
y Supports Optical S/PDIF output
USB
y AMD
®
X570 Chipset
 6x USB 3.2 Gen 1 (SuperSpeed USB) ports (2 Type-A
ports on the back panel, 4 ports available through the
internal USB 3.2 Gen 1 connectors)
 6x USB 2.0 (High-speed USB) ports (2 Type-A ports on
the back panel, 4 ports available through the internal
USB 2.0 connectors)
y AMD
®
Processor
 2x USB 3.2 Gen 2 (3rd Gen AMD Ryzen™) or USB 3.2
Gen1 (2nd Gen AMD Ryzen™/ Ryzen™ with Radeon™
Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™
Graphics) ports (1x Type-A & 1x Type-C) on the back
panel
 2x USB 3.2 Gen1 (SuperSpeed USB) Type-A ports on the
back panel
Continued on next page

MSI MPG X570-A PRO Specifications

General

Chipset	AMD X570
CPU Socket	AM4
Form Factor	ATX
Memory Slots	4
Max Memory	128 GB
SATA Ports	6
LAN	Realtek RTL8111H Gigabit LAN
RAID Support	RAID 0, 1, 10
Multi-GPU Support	AMD CrossFire
Memory Speed	DDR4 4400MHz (OC)
M.2 Slots	2 x M.2
Audio	Realtek ALC1220
PCIe Slots	2 x PCIe 4.0 x16, 2 x PCIe 4.0 x1
USB Ports	2 x USB 3.2 Gen 2 (1 Type-A, 1 Type-C), 8 x USB 3.2 Gen 1 (4 on back panel, 4 via internal connectors), 6 x USB 2.0
