Overview of Components

Component Contents

Port Name Port Type Page

CPU_FAN1, PUMP_FAN1, SYS_FAN1~4 Fan Connectors 33

CPU_PWR1~2, ATX_PWR1 Power Connectors 32

CPU Socket AM4 CPU Socket 27

DIMMA1/A2/B1/B2 DIMM Slots 28

JAUD1 Front Audio Connector 35

JBAT1

Clear CMOS (Reset BIOS)

Jumper

JCI1 Chassis Intrusion Connector 36

JCOM1 Serial Port Connector 35

JFP1, JFP2 Front Panel Connectors 31

JRAINBOW1~2

Addressable RGB LED

connectors

JRGB1~2 RGB LED connectors 38

JUSB1~2 USB 2.0 Connectors 34

JUSB3~4 USB 3.2 Gen1 Connectors 34

M2_1~2 M.2 Slots (Key M) 30

PCI_E1~5 PCIe Expansion Slots 29

SATA1~6 SATA 6Gb/s Connectors 31

Questions and Answers:

Need help?

Do you have a question about the MSI MPG X570-A PRO and is the answer not in the manual?

MSI MPG X570-A PRO Specifications

General

Chipset	AMD X570
CPU Socket	AM4
Form Factor	ATX
Memory Slots	4
Max Memory	128 GB
SATA Ports	6
LAN	Realtek RTL8111H Gigabit LAN
RAID Support	RAID 0, 1, 10
Multi-GPU Support	AMD CrossFire
Memory Speed	DDR4 4400MHz (OC)
M.2 Slots	2 x M.2
Audio	Realtek ALC1220
PCIe Slots	2 x PCIe 4.0 x16, 2 x PCIe 4.0 x1
USB Ports	2 x USB 3.2 Gen 2 (1 Type-A, 1 Type-C), 8 x USB 3.2 Gen 1 (4 on back panel, 4 via internal connectors), 6 x USB 2.0
