7
Specifications
Continued from previous page
AMD X570 Chipset
4x USB 3.2 Gen 1 5Gbps ports are available through
internal USB connectors
2x USB 2.0 ports on the back panel
Asmedia® 1074 Chipset
panel
GL850G Hub
4x USB 2.0 ports are available through the internal
USB connectors
AMD Processor
Storage
6x SATA 6Gb/s ports (From X570 chipset)*
3x M.2 slots (Key M)*
Supports PCIe 4.0 / PCIe 3.0
PCIe 4.0 is available only on AMD Ryzen™ 5000
Series and 3000 Series desktop processors
Support SATA 6Gbps
M2_1 (From processor)
Supports 2242/ 2260/ 2280/ 22110 storage devices
M2_2 (From X570 chipset)
Supports 2242/ 2260/ 2280 storage devices
M2_3* (From X570 chipset)
Supports 2242/ 2260/ 2280 storage devices
* SATA5 and SATA6 will be unavailable when installing M.2 PCIe SSD in the
M2_3 slot.
RAID
AMD X570 Chipset
Supports RAID 0, RAID 1 and RAID 10
Audio
Realtek® ALC4080 Codec
Supports S/PDIF output
Continued on next page
