3.10 CPU Plug & Play III
This Special Features Setup is used by System Hardware Monitor chipset.
You can manually change the value of each option.
ROM PCI/ISA BIOS (2A6LGM4E)
INTEGRATED PERIPHERALS
AWARD SOFTWARE, INC.
*******CPU PLUG & PLAY III********
Adjust CPU Voltage :2.00V
CPU Speed :Manual
CPU Ratio : x3
CPU Frequency : 100/33MHz(Off)
On/Off means Spread Spectrum (
↑ )
******** POST SHOWING ********
Chassis Fan Detected :Disabled
Power Fan Detected :Disabled
CPU Fan Detected :Enabled
Chassis Intrusion Detect :Disabled
Voltage Detected :Enabled
Vcore Voltage Detected :Enabled
+2.5V Voltage Detected :Enabled
+3.3V Voltage Detected :Enabled
+5.0V Voltage Detected :Enabled
+ 12V Voltage Detected :Enabled
- 12V Voltage Detected :Enabled
-5.0V Voltage Detected :Enabled
VBAT Voltage Detected :Enabled
5VSB Voltage Detected :Enabled
Esc : Quit ↑ ↓ → ← : Select item
F1 : Help PU/PD/+/- : modify
F5 : Old Value(Shift) F2 : Color
F6 : Load BIOS Defaults
F7 : Load Setup Defaults
********* SYSTEM MONITOR ********
CPU Fan RPM :5000
System Temperature :
40
0
C/104
0
F
CPU Temperature :35
0
C/93
0
F
TOP TECH. III :Disabled
CPU Critical Temp :Disabled
Shutdown Temp :Disabled
Adjust CPU Voltage
This function is used to adjust the CPU voltage. During
overclocking, the processor might get unstable. Try adjusting the CPU
voltage to lessen the heat generated by the CPU voltage.
NOTE: We do not guarantee that Motherboard or other components will
work properly after overclocking.
********Chipset Feature********
Chipset Voltage Adjust :3.3V
To Next Page
