DDR Population Rules
Install at least one DIMM module on the slots. Each DIMM slot sup-
ports up to a maximum size of 1GB. Users can install either single- or double-
sided modules to meet their own needs. Please note that Channel A DIMMs
(DIMM1 & DIMM2) can respectively work alone, but Channel B DIMMs
(DIMM3 & DIMM4) must work in pair with Channel A DIMMs. In order to
have better performance, it is recommended to install memory modules of the
same type and density on DDR DIMMs “in pairs” -- {DIMM1 & DIMM3}
{DIMM2 & DIMM4}.
Please refer to the following table for detailed DDR population:
DIMM1 (Ch A) DIMM2 (Ch A) DIMM3 (Ch B) DIMM4 (Ch B) System Density
128MB~1GB 128MB~1GB
128MB~1GB 128MB~1GB
128MB~1GB * 128MB~1GB * 256MB~2GB
128MB~1GB # 128MB~1GB # 256MB~2GB
128MB~1GB 128MB~1GB 256MB~2GB
128MB~1GB * 128MB~1GB * 128MB~1GB # 128MB~1GB # 512MB~4GB
