2-29
Hardware Setup
BIOS Flash Jumper: JBIOS1
The jumper is used to lock or unlock the boot block area on BIOS. When
unlocked, the BIOS boot block area can be updated. When locked, the BIOS
boot block area cannot be updated.
JBIOS1
BIOS Flash
Locked
BIOS Flash
Unlocked
