MS-6747 M-ATX Mainboard
Mainboard Specifications
CPU
h Supports Socket 478 for Intel
®
Pentium 4 (Socket 478) processor
h Supports Socket 478 for Intel
®
Northwood/Prescott processor
h Supports up to 3.2 GHz or higher speed P4 processor
Chipsets
h Intel
®
Springdale-865PE chipset
- Supports AGP 8x/4x at 0.8V (AGP 3.0) or 4x at 1.5V (not supports 3.3V)
- Supports 133/166/200MHz memory FSB
- Supports 400/533/800MHz Intel NetBurst micro-architecture bus.
h Intel
®
ICH5/ICH5R chipset (421 mBGA)
- AC’97 2.3 interface
- 8 USB 2.0/1.1 ports
- 2 channel Ultra ATA/100 Bus Master IDE controller
- SMBus 2.0 support
- 2 serial ATA Host Controllers (Optional)
- RAID 0 supported by ICH5R (Optional)
Main Memory
h Support eight memory banks using four 184-pin unbuffered DIMM
h Max memory size is 4GB w/o ECC for (1GB/slot)
h Support 2.6V DDR DIMM
Slots
h Three 32-bit Master PCI Bus slot
h One mini PCI slot (Optional)
h One AGP(Accelerated Graphic Port) slot
On-Board IDE
h An IDE controller on the ICH5 chipset provides IDE HDD/CD-ROM with
PIO, Bus Master and Ultra DMA66/100/133 operation modes.
h Can connect up to four IDE devices.
On-Board Peripherals
h On-Board Peripherals include:
- 1 floppy port supports 2 FDD with 360K, 720K, 1.2M, 1.44M and 2.88
Mbytes.
- 1 serial port, 2 serial ports
