6-4
MS-7125 ATX Mainboard
SATARAID5 Features
h RAID 0, RAID 1, RAID 5, RAID 10, and JBOD Groups are supported.
h Supported OS: Win2000/XP/Server 2003.
h RAID Groups can be created and deleted without exiting Windows.
h Hot Spare and On-line Rebuilding. The spare policy supports testing periodically
for a health check of the spare disk.
Spare drive can be global or dedicated to a specific RAID group.
h Supports Auto and Manual rebuild policy for a RAID group.
h System GUI Monitoring Utility:
Displays/Logs/Alerts Users to Vital RAID Group Information.
Manages RAID Group Functions (configures, rebuilds, etc.,).
h Supports the ability to partition and map a segment of disk to a virtual LUN or
disk.
h Supports up to two RAID groups. Any excess capacity on disk drives can be
formatted as independent logical drives.
h Adjustable Stripe Size for RAID 0, RAID 5, and RAID 10.
h Uses the Self-Monitoring, Analysis, and Reporting Technology (SMART) feature
in the attached drives for automatic notification of imminent drive failures.
h Employ RAID recovery algorithms to maintain data integrity in the event of a disk
failure including bad block management.
h Automatically Selects Highest Available Transfer Speed for All SATA Devices.
Supports the following:
Data transfer rate up to 150MB/Sec (SiI3114, SiI3124-1), and 300MB/Sec
(SiI3124-2)
Support up to 4 SATA devices connected to a single controller.
ACPI, SATA 1.0 (SiI3114, Sii3124-1), and SATA 2.0 (SiI3124-2)
h Supports drive roaming capability allowing drives from one controller to be
moved to another without loss of data.
h Employs a task manager for the scheduling of any RAID or disk management
operations including RAID group creation, rebuild, and test.
