2-21
Hardware Setup
The motherboard provides the following button for you to set the computer’s function.
This section will explain how to change your motherboard’s function through the use
of button.
Clear CMOS Button: SW1
There is a CMOS RAM on board that has a power supply from external battery to
keep the system configuration data. With the CMOS RAM, the system can automati-
cally boot OS every time it is turned on. If you want to clear the system configuration,
use the button to clear data. Press the button to clear the data.
SW1
Button
Important
Make sure that you power off the system before clearing CMOS data.
7346v1.0-2-Hardware.p65 2007/3/6, 上午 11:5821
