En-22
MS-7353 Mainboard
LED POST: POST
This LED tells the POST (Power on self test) process. The regular POST processes
are: CPU => DRAM => MCH => ICH => CLK => VGA => LOGO (or POST) => ATA =>
MSIJ. When the POST is complete, the necessary hardware of the system is de-
tected and found to function properly, the LED displays “MSIJ”. If the LED stops
showing the message in sequence, or does not show the “MSIJ” at last, that mean
there is something wrong with the system, In this case, the showing message tells
the hardware not being detected or is not functioning properly. Please refer to the
table below to get more information about the LED message.
Post Status
CPU CPU is not detected or is not operating properly.
DRAM Memory is not detected or is not operating properly.
MCH North bridge is not detected or is not operating properly.
ICH South bridge is not detected or is not operating properly.
CLK Clock generator is not detected or is not operating properly.
VGA Graphics card is not detected or is not operating properly.
LOGO Logo is enabled and is showing on the screen.
POST Logo is disabled to be shown.
ATA IDE or SATA device is not detected or is not operating properly.
MENU F11 is pressed to select the boot device.
CMOS Checksum CMOS is failed.
BIOS checksum CMOS is failed, and F1 is pressed to enter the BIOS Setup.
Or the system is in the BIOS Setup.
MSIJ The operating system is loaded properly.
