MSI MS-7392 - Hardware Setup: Speaker Connections (continued); 4-Channel Speaker Output

MS-7392 Mainboard
B-20
n 4-Channel Mode for 4-Speaker Output
4-Channel Analog Audio Output
1 Line In
2 Line Out (Front channels)
3 MIC
4 Line Out (Rear channels)
5 No function
6 No function
3
1
2
6
4
5
