MSI MS-7392 - Hardware Setup: Speaker Connections (continued); 8-Channel Speaker Output

MS-7392 Mainboard
B-22
n 8-Channel Mode for 8-Speaker Output
8-Channel Analog Audio Output
1 Line In
2 Line Out (Front channels)
3 MIC
4 Line Out (Rear channels)
5 Line Out (Center and Subwoofer channel)
6 Line Out (Side channels)
1
2
6
4
5
3
