MSI MS-7522 - Quick Components Guide

En-4
MS-7522 Mainboard
RE SET
ON
1 2
3
Quick Components Guide
Back Panel,
En-14
CPU, En-6
DDR3, En-10
JPWR3, En-13
JPWR1, En-13
SATA1~8, En-16
SYSFAN1/3, En-17
JCOM1, En-17
JTPM1, En-20
JCI1, En-18
JFP1, JFP2, En-20
JUSB1~3, En-18
CPU_CLK1, En-23
RESET1, En-22
POWER1, En-22
J1394_1, En-19
JCD1, En-17
JAUD1, En-21
PCI, En-24
PCIE, En-24
SYSFAN2,
En-17
JSP1,
En-19
CPUFAN, En-17
