MSI MS-7522 - Guide Rapide des Composants

Fr-4
Carte mère MS-7522
RE SET
ON
1 2
3
Guide Rapide Des Composants
Panneau
arrière,
Fr-14
CPU, Fr-6
DDR3, Fr-10
JPWR3, Fr-13
JPWR1, Fr-13
SATA1~8, Fr-16
SYSFAN1/3, Fr-17
JCOM1, Fr-17
JTPM1, Fr-20
JCI1, Fr-18
JFP1, JFP2, Fr-20
JUSB1~3, Fr-18
CPU_CLK1, Fr-23
RESET1, Fr-22
POWER1, Fr-22
J1394_1, Fr-19
JCD1, Fr-17
JAUD1, Fr-21
PCI, Fr-24
PCIE, Fr-24
SYSFAN2,
Fr-17
JSP1,
Fr-19
CPUFAN, Fr-17
