MS-7599 Manboard ▍
OC Dal Adjusted FSB Clock (MHz)
It shows the adjusted FSB clock by OC Dal functon (FSB Clock +OC Dal Value).
Read-only.
MEMORY-Z
Press <Enter> to enter the sub-menu.
DIMM1~4 Memory SPD Informaton
Press <Enter> to enter the sub-menu. The sub-menu dsplays the nformaton of
nstalled memory.
Advance DRAM Con󰘰guraton
Press <Enter> to enter the sub-menu.
DRAM Tmng Mode
Ths 󰘰eld has the capacty to automatcally detect all of the DRAM tmng.
DRAM Drve Strength
Ths tem allows you to control the memory data bus’ sgnal strength. Increasng the
drve strength of the memory bus can ncrease stablty durng overclockng.
DRAM Advance Control
Ths 󰘰eld has the capacty to automatcally detect the advanced DRAM tmng.
1T/2T Memory Tmng
Ths tem controls the SDRAM command rate. Select [1T] makes SDRAM sgnal
controller to run at 1T (T=clock cycles) rate. Selectng [2T] makes SDRAM sgnal
controller run at 2T rate.
DCT Unganged Mode
Ths feature s used to Integrate two 64-bt DCTs nto a 128-bt nterface.
Bank Interleavng
Bank Interleavng s an mportant parameter for mprovng overclockng capablty of
memory. It allows system to access multple banks smultaneously.
Power Down Enable
Ths s a memory power-savng technology. When the system does not access mem
-
ory over a perod of tme, t wll automatcally reduce the memory power supply.
MemClk Trstate C3/ATLVID
Ths settng allows you to enable/dsable the MemClk Trstatng durng C3 and
ATLVID.
FSB/DRAM Rato
Ths tem allows you to select the rato of FSB/ DRAM.
Adjusted DRAM Frequency (MHz)
It shows the adjusted Memory frequency. Read-only.
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
