1-3
Getting Started
MS-7666
Chapter 1
Connectors
Back panel
1 PS/2 keyboard port
1 PS/2 mouse port
1 Clear CMOS button
1 D-LED2 panel connector
1 1394 port
5 USB 2.0 ports
1 ESATA port
1 ESATA/ USB 2.0 Combo port
2 LAN ports
2 USB 3.0 ports
On-Board
2 USB 2.0 connectors
1 1394 connector
1 Chassis Intrusion connector
1 TPM Module connector
1 Reset button
1 Power button
1 GreenPower Genie connector (optional)
1 Over-Voltage switch
1 set voltage check point
1 OC Genie button
2 Base clock control buttons
1 set Debug LED panel
Slots
6 PCI Express 2.0 x16 slots (PCI_E2 & PCI_E5 support up to PCIE x16 speed, PCI_
E4 & PCI_E6 support up to PCIE x8 speed, PCI_E3 & PCI_E7 support up to PCIE
x4 speed)
1 PCI Express 1.1 x1 slot
Form Factor
ATX (24.4cm X 30.5 cm)
Mounting
9 mounting holes
Feature on Focus
All Solid Cap design
Hi-C Cap on PWM
Active Phase Switch feature to save power dynamically
OC Genie
Heat Pipe design
EZ Button
USB Save Guard
■
-
-
-
-
-
-
-
-
-
-
■
-
-
-
-
-
-
-
-
-
-
-
-
■
■
■
■
■
■
■
■
■
■
■
