MS-7667
Chapter 1
Connectors/ Ports
Back panel
1 Coaxial S/PDIF-Out
1 Optical S/PDIF-Out
1 IEEE 1394 port
6 USB 2.0 ports
1 eSATA port
1 LAN port
6 󰘱exible audio ports
On-Board
2 USB 2.0 connector
2 USB 3.0 ports
1 Front Panel Audio connector
1 OC switch /LED connector
Slots
2 PCIE 2.0 x16 slots
2 PCIE 2.0 x1 slots
Form Factor
Micro-ATX (24.4 cm X 24.4 cm)
Mounting
8 mounting holes
■
-
-
-
-
-
-
-
■
-
-
-
-
■
■
■
■
