MSI MS-7758 (v3.x) User Manual

1-26
Gettng Started
JUSB1~2: USB 2.0 Expanson Connectors
Ths connector s desgned for connectng hgh-speed USB perpherals such as USB
HDDs, dgtal cameras, MP3 players, prnters, modems, and many others.
11
5V
1.VC
C
3.USB0
-
10.NC
5.USB0
+
7
.Groun d
9.No
Pin
8
.Groun d
6.USB1
+
4.USB1
-
2.VC
C
* The MB layout n ths 󰘰gure s for reference only.
USB 2.0 Bracket (optonal)
Important
Note that the VCC and GND pns must be connected correctly to avod possble
damage.
JCI1: Chasss Intruson Connector
Ths connector connects to the chasss ntruson swtch cable. If the computer case s
opened, the chasss ntruson mechansm wll be actvated. The system wll record ths
ntruson and a warnng message wll 󰘱ash on screen. To clear the warnng, you must
enter the BIOS utlty and clear the record.
1
.
C
I
N
T
R
U
2
.
G
r
o
u
n
d
