Chapter 1
JDLED3: Voce Gene Connector (optonal)
Ths connector s used to lnk to the voce control module (optonal). Please refer to ts
user gude for more detals and usages.
10.No
Pi
n
14.Reserve
d p
in
8.Contro
l p
in
12.Reserve
d p
in
6.VCC3
4.Contro
l pin
2.Contro
l pin
1.5VSB
3.Contro
l pin
5.Contro
l p
in
7.Contro
l p
in
9
.Ground
11
.
Reserve
d p
in
13.Ground
JTURBO1: MultConnect Panel Connector (optonal)
Ths connector s used to connect an optonal front panel for controlng the OC Gene and
some addtonal functons. Please refer to ts user gude for more detals and usages.
3
.TURB
O
4.No
Pi
n
2
.Ground
1
.TURB
O
