MSI MS-7798 (v2.x) User Manual

2-8
BIOS Setup
Seral (COM) Port0
Ths tem allows you to enable/ dsable the seral port.
Seral (COM) Port0 Settngs
Select an address and correspondng nterrupt for the seral port.
Parallel(LPT) Port Con󰘰guraton
Press <Enter> to enter the sub-menu.
Parallel(LPT) Port
Ths tem allows you to enable/ dsable the parallel port.
Parallel(LPT) Port Settngs
Select an address and correspondng nterrupt for the parallel port.
Devce Mode
Select a devce mode for the parallel port.
Hardware Montor
Press <Enter> to enter the sub-menu.
CPU Smart Fan Target
Controls CPU fan speed automatcally dependng on the current temperature and
to keep t wth a spec󰘰c range. If the current CPU temperature reaches the target
value, the smart fan functon wll be actvated.
SYS Fan1 Control
Ths tem allows users to select how percentage of speed for the SYSFAN1.
CPU/ System Temperature, CPU FAN/ SYS FAN 1/ 2 Speed
These tems show the current status of all of the montored hardware devces/ com
-
ponents such as CPU temperature/ system temperature and the few fans’ speeds.
Intel(R) Smart Connect Con󰘰guraton
Press <Enter> to enter the sub-menu.
Intel(R) Smart Connect Technology
Ths tem allows you to enable/ dsable Intel
®
Smart Connect Technology. When you
enable t, the system wll be woked perodcally from Sleep/Standy mode for a bref
perod of tme to update programs.
Power Management Setup
Press <Enter> to enter the sub-menu.
EuP 2013
Energy Usng Products Lot 6 2013 (EUP) reduces power consumpton when system
s o󰘯 or n standby mode.
Note: When enabled, the system wll not support RTC wake up event functons.
Restore after AC Power Loss
Ths tem spec󰘰es whether your system wll reboot after a power falure or nterrupt
occurs. Settngs are:
[Power O󰘯] Always leaves the computer n the power o󰘯 state.
[Power On] Always leaves the computer n the power on state.
[Last State] Restore the system to the status before power falure or nterrupt
occurred.
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
