may fal to retan data. Ths tem apples only when synchronous DRAM s nstalled

n the system.

tRAS

Determnes the tme RAS (row address strobe) takes to read from and wrte to mem

ory cell.

tRFC

Ths settng determnes the tme RFC takes to read from and wrte to a memory

cell.

tWR

Determnes mnmum tme nterval between end of wrte data burst and the start of a

pre-charge command. Allows sense ampl󰘰ers to restore data to cell.

tWTR

Determnes mnmum tme nterval between the end of wrte data burst and the start

of a column-read command; allows I/O gatng to overdrve sense ampl󰘰es before

read command starts.

tRRD

Spec󰘰es the actve-to-actve delay of d󰘯erent banks.

tRTP

Tme nterval between a read and a precharge command.

tFAW

Ths tem s used to set the tFAW (four actvate wndow delay) tmng.

tWCL

Ths tem s used to set the tWCL (Wrte CAS Latency) tmng.

tCKE

Ths tem s used to set the Pulse Wdth for DRAM module.

tRTL

Ths tem s used to set Round Trp Latency settngs.

Advanced Channel 1/ 2 Tmng Con󰘰guraton

Press <Enter> to enter the sub-menu. And you can set the advanced memory tmng

for each channel.

GT OverClockng

Ths tem allows you to enable/ dsable the overclockng of ntegrated graphcs.

GT Rato

Ths settng controls the rato of ntegrated graphcs frequency to enable the ntegrated

graphcs to run at d󰘯erent frequency combnatons.

Adjusted GT Frequency

It shows the GPU frequency. Read-only.

▶
