2-7
MS-9856
SPI Flash ROM Connector: JSPI1
This connector is used to ash SPI ash ROM.
10
JSPI1
9
2
1
PIN SIGNAL PIN SIGNAL
1
3
5
7
9
VCC3_SB
SPI_MISO_F
SPI_CS0_F#
GND
SPI_HOLD#
2
4
6
8
10
VCC3_SB
SPI_MOSI_F
SPI_CLK_F
GND
NC
Keyboard/Mouse Connector: JKBMS1
This connector is used to connect PS/2 keyboard & mouse.
2
1
10
9
JKBMS1
PIN SIGNAL PIN SIGNAL
1
3
5
7
9
VCC5
NC
GND
MSCLK_PH#
MSDAT_PH#
2
4
6
8
10
VCC5
NC
GND
KBCLK_PH#
KBDAT_PH#
