3-19
MS-9897
Deep S5
The setting enables/disables the Deep S5 power saving mode. S5 is almost
the same as G3 Mechanical Off, except that the PSU still supplies power,
at a minimum, to the power button to allow return to S0. A full reboot is
required. No previous content is retained. Other components may remain
powered so the computer can “wake” on input from the keyboard, clock,
modem, LAN, or USB device.
Resume on USB from S3/S4
The item allows the activity of the USB device to wake up the system from
S3/S4 sleep state.
Resume on 82579 LAN
This eld species whether the system will be awakened from power saving
modes when activity or input signal of onboard LAN is detected.
Resume on PCIE PME
This eld species whether the system will be awakened from power saving
modes when activity or input signal of onboard PCIE PME is detected.
Resume on RING
An input signal on the serial Ring Indicator (RI) line (in other words, an
incoming call on the modem) awakens the system from a soft off state.
Resume on RTC
When [Enabled], your can set the date and time at which the RTC (real-time
clock) alarm awakens the system from suspend mode.
