MSI MS-9897 - Table of Contents

vii
MS-9897
Contents
Copyright Notice .................................................................................ii
Trademarks .........................................................................................ii
Revision History ..................................................................................ii
Safety Instructions ............................................................................. iii
CE Conformity ....................................................................................iv
FCC-B Radio Frequency Interference Statement ..............................iv
WEEE Statement ................................................................................v
Chapter 1 Overview ������������������������������������������������������������������������������� 1-1
Mainboard Specications ................................................................ 1-2
Mainboard Layout ........................................................................... 1-4
Chapter 2 Hardware Setup�������������������������������������������������������������������� 2-1
Quick Components Guide ............................................................... 2-2
Memory ........................................................................................... 2-3
Power Supply .................................................................................. 2-4
Back Panel I/O ................................................................................ 2-5
Connector ....................................................................................... 2-7
Jumper .......................................................................................... 2-13
Slot ................................................................................................ 2-16
Chapter 3 BIOS Setup ��������������������������������������������������������������������������� 3-1
Entering Setup ................................................................................ 3-2
The Menu Bar ................................................................................. 3-4
Main ................................................................................................ 3-5
Advanced ........................................................................................ 3-7
Boot ............................................................................................... 3-12
Security ......................................................................................... 3-13
Chipset .......................................................................................... 3-16
Power ............................................................................................ 3-18
Save & Exit ................................................................................... 3-20
Chapter 4 System Resources ��������������������������������������������������������������� 4-1
