Overview Industrial Computer Board
1-3
Overview Industrial Computer Board
Onboard Pin Headers/ Connectors/ Jumpers
1 SATA 3Gb/s port
1 CPU fan connector
1 SATA power connector
1 DC power connector
1 TPM pin header
5 RS-232 serial port connectors
1 parallel port connector
1 GPIO pin header
1 front panel pin header
1 front audio pin header
1 amplifier pin header
1 mouse/keyboard connector
1 LVDS connector
1 chassis intrusion pin header
1 clear CMOS jumper
1 LVDS power jumper
1 serial port power jumper
1 AT/ATX select jumper
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
Slot
1 PCIe x1 slot
1 Mini-PCIe slot
■
■
Form Factor
Mini-ITX form factor: 170mm x 170mm ■
Environmental
Operating Temperature: 0
o
C ~ 60
o
C
Storage Temperature: -20
o
C ~ 80
o
C
Humidity: 10% ~ 90% RH, Non-Condensing
■
■
■
