Overview MS-S0891
1-3
Overview MS-S0891
Onboard Pinheaders/ Connectors/ Jumpers
1 TPM pinheader
1 front panel pinheader
1 4-pin 12V power connector (ATX SKU, ATX IPMI SKU)
1 24-pin power connector (ATX SKU, ATX IPMI SKU)
1 4-pin 19V power connector (DC-in SKU)
1 4-pin SATA power connector (DC-in SKU)
3 system fan connectors
1 clear CMOS jumper
1 serial port connector
1 USB 2.0 pinheader
■
■
■
■
■
■
■
■
■
■
Slot
1 PCIe 3.0 x16 slot (x8 signal, for ATX SKU and ATX IPMI SKU only)■
Form Factor
ITX form factor: 17cm x 17cm■
Mounting
4 mounting holes■
SKU Comparison
SKUs
Features
ATX SKU DC-in SKU ATX IPMI SKU
AST1300 (w/ VGA) V V
AST2300 (w/ IPMI) V
SATA 6 G/bs qty 2 2 2
SATA 3 G/bs qty 3 2 3
eSATA port V V
PCI_E2 PCIe x16
(x8 signal)
V V
