Hardware Setup MS-S0891
2-11
Hardware Setup MS-S0891
Rear Panel I/O
ATX/ ATX IPMI SKU
DC-in SKU
VGA Port JLAN2 JLAN1 (share
NIC, for IPMI only)
eSATA Port
USB 3.0 Port
VGA Port JLAN2 JLAN1DC Power Jack USB 3.0 Port
DC Power Jack (DC-in SKU)
This connector provides 19V power to the system.
eSATA Port (ATX/ ATX IPMI SKU)
eSATA is External Serial ATA interface. Serial ATA is a commonly used interface
for internal hard drives, and eSATA is an extension of SATA specication to be
used with external devices.
USB 3.0 Port
The USB 3.0 port is backward-compatible with USB 2.0 devices. It supports up to
5Gbit/s (SuperSpeed) data transfer rate.
VGA Port
The DB15-pin female connector is provided for monitor.
▶
▶
▶
▶
