USB 2.0 Connector: JUSB1
This connector, compliant with Intel I/O Connectivity Design Guide, is ideal for
connecting high-speed USB interface peripherals such as USB HDD, digital cam-
eras, MP3 players, printers, modems and the like.
1.VC
C
3.USB0
-
10.NC
5.USB0
+
7
.Ground
9.No
Pi
n
8
.Ground
6.USB1
+
4.USB1
-
2.VC
C
Important
Note that the pins of VCC and GND must be connected correctly to avoid pos-
sible damage.
TPM Module Connector: JTPM1
This connector connects to a TPM (Trusted Platform Module) module (optional).
Please refer to the TPM security platform manual for more details.
10.No
Pi
n
14.Ground
8.5V
P
ower
12.Ground
6.Serial
IR
Q
4.3.3V
P
ower
2.3V
Standby
p
ower
1.LP
C C
loc
k
3.LP
C R
eset
5.LP
C a
ddres
s & d
at
a p
in0
7.LP
C a
ddres
s & d
at
a p
in1
9.LP
C a
ddres
s & d
at
a p
in2
11
.LPC
a
ddres
s & d
at
a p
in3
13.LPC F
rame
