Hardware Setup
MS-7681
Chapter 2
2-11
Hardware Setup
MS-7681
Chapter 2
Back Panel
Mouse/Keyboard
The standard PS/2
®
mouse/keyboard DIN connector s for a PS/2
®
mouse/keyboard.
Clear CMOS Button (optonal)
There s a CMOS RAM on board that has a power supply from external battery to keep
the system con󰘰guraton data. Wth the CMOS RAM, the system can automatcally
boot OS every tme t s turned on. If you want to clear the system con󰘰guraton, use
the button to clear data. Press the button to clear the data.
Important
Make sure that you power o󰘯 the system before clearng CMOS data.
After pressng ths button to clear CMOS data n power o󰘯 (G3) state, the system wll
boot automatcally.
Coaxal S/PDIF-Out (optonal)
Ths SPDIF (Sony & Phlps Dgtal Interconnect Format) connector s provded for dgtal
audo transmsson to external speakers through a coaxal cable.
Optcal S/PDIF-Out (optonal)
Ths SPDIF (Sony & Phlps Dgtal Interconnect Format) connector s provded for dgtal
audo transmsson to external speakers through an optcal 󰘰ber cable.
IEEE 1394 Port (optonal)
The IEEE 1394 port on the back panel provdes connecton to IEEE 1394 devces.
eSATA Port (optonal)
The eSATA (External SATA) port s for attachng the eSATA hard drve.
Mouse/
Keyboard
LAN
Lne-In
Lne-Out
Mc
IEEE 1394 Port
(optonal)
USB 3.0 Port
(optonal)
RS-Out
CS-Out
SS-OutUSB 2.0 Port
Clear CMOS Button
(optonal)
Optcal
S/PDIF-Out
(optonal)
Coaxal
S/PDIF-Out
(optonal)
USB 2.0 Port
eSATA Port
(optonal)
USB 2.0 Port
