MSI P67A-GD65 Series User Manual

Hardware Setup
MS-7681
Chapter 2
2-15
Hardware Setup
MS-7681
Chapter 2
Front USB 2.0 Connector: JUSB1
Ths connector, complant wth Intel
®
I/O Connectvty Desgn Gude, s deal for con-
nectng hgh-speed USB nterface perpherals such as USB HDD, dgtal cameras, MP3
players, prnters, modems and the lke.
11
5V
1.VC
C
3.USB0
-
10.NC
5.USB0
+
7
.Ground
9.No
Pin
8
.Ground
6.USB1
+
4.USB1
-
2.VC
C
* The MB layout n ths 󰘰gure s for reference only.
USB Bracket (optonal)
Important
Note that the pns of VCC and GND must be connected correctly to avod possble
damage.
The JUSB1 (red mark) supports MSI newly Super-Charger technology. Wth Super-
Charger technology, the JUSB1 can only provde chargng functon n S0 (power-on),
S3 (sleep mode) & S5 (shut-down) states. However, the synchronzng data lnk wll
be dsabled. In ths case, the system can not be awaked through the JUSB1.
For Super-Charger n S3 (sleep mode)/ S5 (shut-down), we suggest you to connect
only one devce for stable chargng.
Super-Charger technology would be avalable on spec󰘰c models, please refer to MSI
webste for model support lst.
•
•
•
•
