MSI P67A-GD65 Series User Manual

2-22
Hardware Setup
MS-7681
Chapter 2
Hardware Setup
MS-7681
Chapter 2
Voltage Check Pont: FV1 (optonal)
Ths voltage check pont set s used to measure the current CPU/ CPU_VTT/ CPU_
GFX/ DDR/ PCH voltage.
CPU voltage: measure the current CPU voltage
wth CPU pont and GND pont by usng a mul-
tmeter.
CPU_VTT voltage: measure the current CPU_
VTT voltage wth CPU_VTT pont and GND
pont by usng a multmeter.
DDR voltage: measure the current DDR voltage
wth DDR pont and GND pont by usng a mul-
tmeter.
PCH voltage: measure the current PCH voltage
wth PCH pont and GND pont by usng a mul-
tmeter.
DDR
GND
GND
1
7
PCHCPU_SA
CPU_VTT
CPU
GND
1
7
CPU
GND
1
7
CPU_VTT
GND
1
7
CPU_SA
GND
1
7
DDR
GND
1
7
PCH
CPU_SA voltage: measure the current CPU_SA
voltage wth CPU_SA pont and GND pont by
usng a multmeter.
