MSI Trident Series - Removing CPU Cooler

•
Service Manual
---- - --- -- . - - -- -- - --
Compatible M.2 SSD Type
A~
For users who want to purchase the M.2 SSD by themselves, please consult the
local dealer for M.2 SSD type: Key B+M.
> Removing CPU Cooler
Step 1. Unlock the screw of the plastic
bracket and the screw
on the CPU fan
module.
A~
M3X5 screws * 2.
Step 2. Remove the plastic bracket.
Step 3. Unplug the fan power cable of
the CPU fan module.
Trident Series
,,/'
,,,,.../
